Introduction¶

In the algorithmic trading world, parameterization is so common that some algorithms are configured with hundreds or thousands of parameters. An algorithmic parent order can easily has hundreds of parameters and some of which are exposed to algorithm users so that they can update the order attributes. For example, the participation rate of a POV (Percent Of Volume) order can be amended by end users at any time during the trading duration. A common question encountered in the analysis of algorithm and/or smart order router behavior is

what parameters are modified, and
how they are updated

when an amend event is initiated by an algorithmic trader.

Question¶

Below is an example history of a few selected parameters of a POV order. Create a table to show the parameter history with each parameter name as the column name in the table. You need to treat the change in order quantity and/or price limit the same as parameter change.

paramTbl:([]time:`time$();orderQty:`long$();limitPrice:`float$();params:());
`paramTbl insert (09:30:56.123;500000;0n;`StartTime`PovRate!(10:00:00.000;0.08));
`paramTbl insert (09:35:44.735;500000;0n;`StartTime`PovRate!(09:40:00.000;0.08));
`paramTbl insert (10:01:25.941;500000;0n;`StartTime`PovRate!(09:40:00.000;0.12));
`paramTbl insert (10:10:32.356;500000;0n;`StartTime`PovRate`MinPovRate`MaxPovRate!(09:40:00.000;0.12;0.10;0.14));
`paramTbl insert (10:30:39.475;500000;45.23;`StartTime`PovRate`MinPovRate`MaxPovRate!(09:40:00.000;0.12;0.10;0.14));
`paramTbl insert (11:00:52.092;600000;45.27;`StartTime`PovRate`MinPovRate`MaxPovRate!(09:40:00.000;0.12;0.10;0.14));
`paramTbl insert (11:00:52.092;1000000;0n;`StartTime`PovRate!(09:40:00.000;0.15));

The final output table should look like as follows. Note in kdb table, the empty cell in the table below should have proper null value.

time	OrderQty	LimitPrice	StartTime	PovRate	MinPovRate	MaxPovRate
09:30:56.123	500000		10:00:00.000	0.08
09:35:44.735	500000		09:40:00.000	0.08
10:01:25.941	500000		09:40:00.000	0.12
10:10:32.356	500000		09:40:00.000	0.12	0.1	0.14
10:30:39.475	500000	45.23	09:40:00.000	0.12	0.1	0.14
11:00:52.092	600000	45.27	09:40:00.000	0.12	0.1	0.14
11:00:52.092	1000000		09:40:00.000	0.15

Answer¶

The answer below shows a few tips on dictionary manipulation:

Use raze to merge a list of dictionaries with values of possible different types into a single dictionary
Find the proper null values for each dictionary key
Merge two dictionaries with join operator
Merge two tables side by side

{[paramTbl]
  / Merge all parameters into a single dictionary so as to get a full list of parameter names
  allParams:raze exec params from paramTbl;

  / Find the null value for each parameter name
  nullValues:(key allParams)!(enlist each value allParams)[;1];

  / Create a table of "parameter" change history of order qty and limit price
  params1:select time,OrderQty:orderQty,LimitPrice:limitPrice from paramTbl;

  / Set a proper null value to parameters that are not present
  params2:exec {x,y}[nullValues;] each params from paramTbl;

  / Combine the normal parameters with the pseudo parameters
  params1,'params2
}[paramTbl]
